4 Axles 100 Tons Semi Low Bed Trailer

4 Axles 100 Tons Semi Low Bed Trailer Description:

The ramp of 4 axles 100 tons semi low bed trailer ladders is welded with H60 steel of high strength steel plate, which has strong bearing capacity and effectively ensures that the weight of excavator or other heavy equipment can pass through the spring ramp without deformation or damage. The service can up to more than 5 years, other factories use channel steel welding, it is easy to collapse.

4 Axles 100 Tons Semi Low Bed Trailer for Sale in dar es salaam Tanzania

4 Axles 100 Tons Semi Low Bed Trailer for Sale in dar es salaam Tanzania

4 Axles 100 Tons Semi Low Bed Trailer for Sale in dar es salaam Tanzania

4 Axles 100 Tons Semi Low Bed Trailer for Sale in dar es salaam Tanzania

4 Axles 100 Tons Semi Low Bed Trailer Specification：

Overall dimension: 15800mm * 3000mm *3400mm

Loading capacity(T): 100T

Axle: 13T/16T, FUWA / BPW / TITAN Brand

Rim: 8.0-20

Tire: 11.00R20

Suspension: Mechanical suspension

Spring leaf: 90(W)mmx13(Thickness)mmx10 layers

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

Landing gear: JOST brand

Main beam: Height: 500mm, Upper plate: 20mm, Middle plate: 12mm, Lower plate: 20mm, Material: Q345B steel.

Bottom Platform: 5mm thick checkered plate

Ramp: hydraulic type

Gooseneck: Optional

ABS: Optional

Valve: WABCO valve

Light: LED light (specially intended for oversea markets)

4 Axles 100 Tons Semi Low Bed Trailer Advantage:

1. Main beam adopts HG high strength steel, with high loading capacity.

2. Side beam adopt “H” steel, the durable design avoid the side beam to have the deformation.

3. The loading ramps is made by high strength steel, with high loading capacity, will not happen to the deformation when carry heavy equipment.

4. polyurethane paint, with long service lift, and avoid the vehicle get rust.

5. World famous brand spare part, ensure high quality and save costs.

4 Axles 100 Tons Semi Low Bed Trailer details display video

Please click "TITAN Lowbed Trailer" to get detailed video!

Welcome to leave your inquiry! We will provide more details, price, catalog, drawing, videos for you!
