Semi Dump Trailer Capacity 100 Ton adopts high strength steel to make it durable when loading the sand or small stones or rocks.
Semi Dump Trailer Capacity 100 Ton adopts high strength steel to make it durable when loading the sand or small stones or rocks. And the Semi Dump Trailer Capacity 100 Ton for Sale loading capacity is 40t, 60t, 80t, 100T.
TITAN Semi Dump Trailer Capacity 100 Ton Manufacturer equipped with reliable hydraulic cylinder. We can customize the tipper trailers according to your special need, like U shape dump, end dump, side tipper, and container tippers
Rear Semi Dump Trailer Capacity 100 Ton for Sale in Senegal Dakar
tri axle semi dump trailer for sale
Dimension: 8500mmx2500mm x3950mm ( inside dimension )
Main beam: Height: 480mm, Upper plate: 14mm, Middle plate: 8mm, Lower plate: 14mm, Material: T700 steel.
Bottom Platform: 4 thick checkered plate
Side wall thickness: 4mm
Total volume(m³): 30m³
End plate: 8mm
Lifting System: Full set of HYVA lifting cylinder
Axle: 13T/16T, FUWA / BPW / TITAN Brand
Rim: 8.0-20 or 9.00-20
Tire: 8.25R20/10.00R20/11.00R20/12R22.5
Suspension: Mechanical suspension
Spring leaf: 90(W)mmx13(Thickness)mmx10 layers
Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)
Landing gear: JOST brand
ABS: Optional
Valve: WABCO valve
Light: LED light (specially intended for oversea markets)
Voltage: 24V
Tool box: 1 set
