3 Axle 60 Ton End Dump Trailers

Product Description：

TITAN 3 axle 60 ton end dump trailers price adopt high strength steel to make it durable when load the sand or small stones or rocks. And the loading capacity is 40t to 60t.

TITAN Tipper Truck Trailers for sale equipped with reliable hydraulic HYVA cylinder.

We can also customize the tipper trailers sale in Ghana according to your special needs, like U shape dump, end dump, side tipper, and container tippers including skeleton and flatbeds trailers.

Tipper Trailer | TITAN 3 Axle 60 Ton End Dump Trailers in Ghana Kumasi Price

Tipper Trailer | TITAN 3 Axle 60 Ton End Dump Trailers in Ghana Kumasi Price

Tipper Trailer | TITAN 3 Axle 60 Ton End Dump Trailers in Ghana Kumasi Price

Specifications:

Dimension: 8500mmx2500mm x3950mm ( inside dimension )

Main beam: Height: 480mm, Upper plate: 14mm, Middle plate: 8mm, Lower plate: 14mm, Material: T700 steel.

Bottom Platform: 4 thick checkered plate

Side wall thickness: 4mm

Total volume(m³): 35m³

End plate: 8mm

Lifting System: Full set of HYVA lifting cylinder

Axle: 13T/16T, FUWA / BPW / TITAN Brand

Rim: 8.0-20 or 9.00-20

Tire: 8.25R20/10.00R20/11.00R20/12R22.5

Suspension: Mechanical suspension

Spring leaf: 90(W)mmx13(Thickness)mmx10 layers

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

Landing gear: JOST brand

ABS: Optional

Valve: WABCO valve

Light: LED light (specially intended for oversea markets)

Voltage: 24V

Tool box: 1 set

Advantage:

1. Hydraulic cylinder: The heavy-duty cylinder with a wider diameter, stronger lifting capacity and higher height, which makes the lifting more stable and does not easy to roll over.

2. Double-plate main beam for tipper semi trailer, which has a stronger carrying capacity, it is not easy to damage.

3. with 4 units vice beam and cross balance beam. The lattice structure of the side door makes the side door more solid.

4. The leaf spring is widened and thickened, the shock absorption effect is good.

5. Strengthened Ribs, unique structure design to maximize the payload.

 3 axle end dump trailer detail show video

Please click " TITAN Tipper Semi Trailer" to get detailed videos!

Welcome to leave your inquiry! We will provide more details, price, catalog, drawing, videos for you!
