Wind Blade Lifter Adaptor
Wind Blade Lifter Adaptor

Wind Blade Lifter Adaptor

100000 USD

Different Parameters, Different Price. Price Reference Only.



These type of wind blade lifter adaptor trailers are used to transport turbine blades on mountain roads and curved roads as well.

SKU: Wind Blade Lifter Adaptor
MPN: TITAN9411067
Brand: TITAN

Wind Blade Lifter Adaptor Product Description:

These type of wind blade lifter adaptor trailers are used to transport turbine blades on mountain roads and curved roads as well. Because of the fact that extendable trailers are too long, when it comes to a mountain road, it is hard to steer hence the need for the special blade trailer. The design is made in such a way that the blade adaptor can lift up and down making it easier for the trailer to steer easily. So many types of Shiyun, Genron, wind blade lifter adaptor , wind blade adaptor , windmill blade transport adaptor for sale worldwide.

The transportation of wind turbine blade equipment belongs to super long and indecomposable large objects. It is technically difficult to protect safety protection equipment without damage and injury. To prevent rear running vehicles from back end collision is a safety difficulty in transportation; Besides nacelle, wind tower section, and other windmill parts, the wind blade is long and lightweight, also fragile and tender. How to make a safe and efficient transport for those blades is our trailer’s purpose.If you want to transport the wind blade to mountain areas or pass narrow roads with U-turns, you may need a wind blade lifter adapter to solve the problem.

Wind Blade Lifter Adaptor for Sale in Vietnam.

Wind Blade Adaptor for Sale in Vietnam

Wind Blade Lifter Adaptor for Sale in Vietnam

Wind Blade Lifter Adaptor for Sale in Vietnam

Wind Blade Lifter Adaptor for Sale in Vietnam

Windmill Blade Transport Adaptor for Sale

wind blade adaptor



Specification:

Brand: TITAN Windmill Blade Transport Adaptor

Loading capacity: 23.5 Tons

Max rotation angle: 360°

Blade elevation range 0°-47°

Blade pitch angle: 0°-360°

Horizontal rotation angle of adaptor: 0°-360°

Counterweight iron block of adaptor rack: 0-16t

Hydraulic station: 40KW Four-cylinder Diesel Engine

Tail: Slewing support cylinder with tooling at the tail (horizontally telescopic); with pusher

Transportable wind blade specification: 121-155 model

Diameter of lifting cylinder: 320mm; four-axis tire 8.25R16



Wind Blade Lifter Adaptor for Sale in Vietnam

Through this video, you can learn more details about 3 line 6 axle windmill rotor blade lifter , windmill rotor blade trailer , Wind Blade Lifter Adaptor , Wind Blade Adaptor , Windmill Blade Transport Adaptor etc.

If you want to know more types of wind blade trailers, please click here "Wind Blade Trailer" to watch the video!

Welcome to leave your inquiry! We will provide more details, price, catalog, drawing, videos for you!



Wind Blade Lifter Adaptor , Wind Blade Adaptor , Windmill Blade Transport Adaptor , Shiyun , Genron
