56m Wind Blade Trailer
56m Wind Blade Trailer 56m Wind Blade Trailer 56m Wind Blade Trailer 56m Wind Blade Trailer 56m Wind Blade Trailer

56m Wind Blade Trailer

61530 USD

Different Parameters, Different Price. Price Reference Only.

SKU: 56m Wind Blade Trailer
GTIN: 6975766110949
MPN: TITAN9411054
Brand: TITAN

TITAN Wind Turbine Blade Trailer for Windmill Turbine Blade Transport

Your road to success



TITAN is a specialized heavy haul trailer manufacturer in China, with more than 15 years production experience and strong technical strength, TITAN semi trailers has successfully entered into over 50 countries and areas around the world, such as Ethiopia, Malawi, Uganda, Mali,Zimbabwe, Zambia, Nigeria, Algeria, Sudan, Kenya, Djibouti, India, Pakistan, Argentina, Chile, Mexico, and so on.



For transporting extremly heavy and long windmill turbine blade - Wind Turbine Blade Trailer from TITAN is the ideal solution, with single to triple extendable decks and a loading length of up to 56 meters, a TITAN Wind Turbine Blade Trailer adapts perfectly to haul 45 meters to 80 meters long windmill turbine blade transportation and long bulky goods.TITAN Wind Turbine Blade Trailer are noted for their highly robust frames and outstanding stability of the extension beam. the high standard of the workmanship and welding process ensures easy adjustment of the extension beams TITAN Wind Turbine Blade Trailer can be adjusted to fit any size or band of Turbine Blade, TITAN can provide you the customize wind blade trailer to meet your transport requirements.



Features - TITAN Wind Blade Trailer



  • Trailer's length from 21. meters extend to 56 meters

  • Transport the 45 meters to 80 meters Windmill Turbine Blade.

  • Loading capacity is up to 60 ton

  • Steerable axles, all wheels steering.

  • Highly robust frames and outstanding stability of extension beam.

  • Mechanical spring suspension, air suspension or hydraulic suspension is an option

  • Manual valve operation and wireless remote control.



Main Specification - TITAN Wind Blade Trailer



Brand TITAN Wind Turbine Blade Trailer
Dimension 21,500mmX3000mmX1350mm
Total length 56,000mm after extension
Loading capacity 60 Ton
Platform thickness 3 mm
Hydraulic power station Diesel engine
Axle 4 units steering axle
Suspension Mechanical spring suspension.
Tyre 16 units, Triangle brand
Braking system WABCO emergency valve
King pin 3.5 inch high tensile steel bolted type
Landing gear JOST C200



TITAN Wind Blade Trailer

TITAN 56 meters Wind Turbine Blade Trailer - www.titanvehicle.com

TITAN Wind Turbine Blade Trailer for Windmill Turbine Blade Transport

TITAN 56 meters Wind Turbine Blade Trailer - www.titanvehicle.com

TITAN Wind Turbine Blade Trailer for Windmill Turbine Blade Transport

TITAN 56 meters Wind Turbine Blade Trailer - www.titanvehicle.com

TITAN Wind Turbine Blade Trailer for Windmill Turbine Blade Transport

Drawing-56 meter Extendable Semi Trailer- TITAN VEHICLE.jpg

TITAN professinoal engineering team will be ready to provide you with a set of well-integrated solutions that meets your transportation needs and also your local regulartions. TITAN engineering team can communicate with you online to fully understand your needs, the solutions include the product design, product material, product drawings, product videos.



All customers and friends are warmly welcomed to our company for visit and business negotiations, TITAN will as always to our best effort to provide you the most durable TITAN Wind Turbine Blade Trailer to support you forever.



If you are interested, welcome to the inquire or online message! Please fill in your contact information and suggestions! Thank you!



We will meet the acme of perfection to serve and provide more details , price ,catalog,drawing ,video for you !



Orders for ready-made or custom-made trailers are welcome!

Review

Phoenix - 2021-06-21T17:06:56+0800
The 56m wind blade trailer is great for my wind turbine blades transporting plan and the customer service is unbelievable
