50 Ton Fence Cargo Truck Trailer
50 Ton Fence Cargo Truck Trailer

50 Ton Fence Cargo Truck Trailer

10000 USD

Different Parameters, Different Price. Price Reference Only.



50 ton fence cargo truck trailer accessories and configuration all adopt international famous brand, this makes the trailer not only increase long serivce life but aslo improve operating efficiency and save maintenance costs.

SKU: 50 Ton Fence Cargo Truck Trailer
GTIN: 06975766111724
MPN: TITAN9405030
Brand: TITAN

Product Description:

Fence cargo truck trailer was popular by logistics companies as its multipurpose application. It uses to load a wide range of products and materials, like sand, bags, poultry, and some bulk cargo.

TITAN 50 ton fence truck trailer deeply loved by foreign customers due to main material used high quality steel-Q345. It has high-strength,strong and sturdy features, stability and safety when operating in harsh road conditions.

In addition, the trailer accessories and configuration all adopt international famous brand and China famous brand, this makes the trailer not only increase long serivce life but aslo improve operating efficiency and save maintenance costs.

50 Ton Fence Cargo Truck Semi Trailer for Sale - TITAN Vehicle

50 Ton Fence Cargo Truck Semi Trailer for Sale in Congo - TITAN Vehicle

50 Ton Fence Cargo Truck Semi Trailer for Sale - TITAN Vehicle



Specifications:

Tare Weight: About 8.3T

Dimension(mm): 12500x2500x3150mm

Trailer Sides: 1600mm

Loading capacity(ton): ≤50T

Axles: 3 axles, 13T/16T ,FUWA/ BPW/ TITAN Brand

Tire: 12 units, 12.00R22.5 or 12.00R24

Rim: 9.00-22.5 or 9.75-22.5

Suspension: Mechanical, Bogie, Airbag suspension(China brand or BPW brand)

Spring Leaf: 90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12 (specially intended for overseas markets)

King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded)

Landing Gear: JOST brand D200T or Chinese brand 28tons(double-speed)

Main Beam: Height: 500mm, Upper plate:14mm, Middle plate:8mm, Bottom plate:16mm, Material:Q345B steel

Side Beam: 16mm or 18mm steel channel (material: Q235 steel)

Bottom Platform: 3mm-thick checkered plate

Brake Chamber: WABCO RE 6 relay valve; T30/30+T30 spring brake chamber(TKL brand), 45L air tank

Twist Locks: 4,8,12 sets (lifting or screw type)

Valve: WABCO valve (specially intended for oversea market)

ABS: Optional

Light: LED light (specially intended for oversea market)

Voltage: 24V

Socket(Receptacle): 7-pin Socket (for 7 wire harness)

Tool Box: 1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs)

Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats



Advantages:

1. TITAN Vehicle adopts high strength steel material to manufacture the side wall semi trailer, it can make the sidewall trailer have a higher loading capacity and a longer service life.

2. TITAN Vehicle uses automatic arc-submerging welding method to weld the main beam, so the main beam is more stronger and more durable.

3. Hight quality side wall, make sure the stable and safety of the loads.

4. Also the trailers floor is checker plate, this will keep the other bulk cargo more stable, like the bags, or long stuff.

5. To make sure the service life of the stake semi trailers, all the spare parts we adopt are world famous brand.



Welcome to leave your inquiry!

We will provide quotation and more details, drawings, pictures, videos for you!
