The main purpose of the TITAN windmill trailer for windmill transportation is to transport windmill components, such as blades, wind tower sections and turbines, etc. Windmill trailer for windmill transportation can also be used for the transportation of over-length cargo
The windmill trailer for windmill transportation adopts a single beam design, and the transportation of the windmill blade on the road will be more stable. At the same time, the steel used to make the single beam is high-strength HG60 steel, which makes the windmill trailer stronger and ensures the stability of transportation.
When cornering, the rear axle of the windmill trailer for windmill transportation has turntables attached to the work platform, these are used for better performance when the windmill trailer is steered.
Windmill Trailer for Windmill Transpotation for Sale in Vietnam
Windmill Trailer for Windmill Transpotation for Sale in Vietnam
Brand: TITAN Windmill Trailer for Windmill Transpotation
Closed length: 24150mmX3000mmX 1650mm
Total length: 62,000mm after extension
Transport: 80m windmill blade
Loading capacity: 90 Ton
Platform thickness: 3 mm
Hydraulic power station: Diesel engine
Tire: 32 units
Axle: 8 axle
Kingpin: 3.5 inch
Landing gear: JOST C200
Suspension: Hydraulic suspension
Braking system: WABCO emergency valve
Windmill Trailer for Windmill Transpotation for Sale in Vietnam
1. The girders of the windmill trailer for windmill transpotation are designed with a buckle box, and the length of the vehicle can be adjusted by pulling the girders to adapt to the transport length of different windmill blades.
2. The work platform is made of 3mm thick diamond steel plate, which makes the goods not easy to slide on the work surface, which is conducive to stable transportation.
3. The characteristics of this windmill trailer are that the frame is firm and the extended beam is stable. TITAN can provide you with the suspension mounted on the windmill trailer: mechanical spring suspension, air suspension or hydraulic suspension.
Windmill Trailer for Windmill Transpotation Display Video
