4 Axle 120 Ton Low Bed Trailers
4 Axle 120 Ton Low Bed Trailers

4 Axle 120 Ton Low Bed Trailers

12800 USD

Different Parameters, Different Price. Price Reference Only.



4 axle low bed trailer use high strength steel material to ensure the capacity, the load can be up to 80 to 120 ton payload.

SKU: 4 Axle 120 Ton Low Bed Trailers
GTIN: 06975766110550
MPN: TITAN9403TDP109
Brand: TITAN

Product description:

TITAN Vehicle offers 4 axle 120 ton heavy haul lowbed semi trailer designed to carry 80 tons, 100 tons, 120 tons. It's main cargo platform is low, which ensures the stability of transportation.

We adopt famous brand parts, like WABCO braking valve, JOST legs, FUWA, BPW axles. This’ll ensure the long service life of the trailers.

Used 4 Axle 120 Ton Heavy Haul Low Bed Trailers for Sale Manufacturers

Used 4 Axle 120 Ton Heavy Haul Low Bed Trailers for Sale Manufacturers

Used 4 Axle 120 Ton Heavy Haul Low Bed Trailers for Sale Manufacturers

Used 4 Axle 120 Ton Heavy Haul Low Bed Trailers for Sale Manufacturers

Used 4 Axle 120 Ton Heavy Haul Low Bed Trailers for Sale Manufacturers

Used 4 Axle 120 Ton Heavy Haul Low Bed Trailers for Sale Manufacturers



Specification:

Overall dimension: 16000mm * 3000mm *3400mm

Loading capacity(T): 120T

Axle: 16T, FUWA / BPW / TITAN Brand

Rim: 8.0-20

Tire: 11.00R20

Suspension: Mechanical suspension

Spring leaf: 90(W)mmx13(Thickness)mmx10 layers

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

Landing gear: JOST brand

Main beam: Height: 500mm, Upper plate: 20mm, Middle plate: 12mm, Lower plate: 20mm, Material: Q345B steel.

Bottom Platform: 5mm thick checkered plate

Ramp: box structure of four vertical HG60 steel plate

Gooseneck: Optional

ABS: Optional

Valve: WABCO valve

Light: LED light (specially intended for oversea markets)

4 Axle 100T Low Bed Truck Trailer  100 Ton Lowbed Semi Trailer for Sale



Advantage:

1. Main beam adopts HG60 high strength steel, with high loading capacity.

2. Side beam adopt “H” shape design, the durable design avoid the side beam to have the deformation.

3. The loading ramps is made by high strength steel, with high loading capacity, the deformation will not happen when carry heavy equipment.

4. polyurethane paint, with long service life, and avoid the vehicle getting rust.

5. World famous brand spare part, ensure high quality and save costs.



Through this video below, you can learn about different types of lowbed semi-trailers, as well as the process, testing, packaging and customer feedback, etc.

Video of Lowbed Semi Trailer for Sale



Please click "TITAN Lowbed Trailer" to get detailed video!



Welcome to leave your inquiry! We will provide more details, price, catalog, drawing, videos for you!

Review

Colarinho from Mozambique - 2022-03-31T10:03:58+0800
Thank you TITAN for your support. Because it is the first time to use 4 axle 120 ton low bed trailer, I am not sure about the operation, Jacky will also tell you how to use it in detail. TITAN's after-sales service is very timely and patient.
